IEC 61169-16:2006 - Radio-frequency connectors - Part 16: Sectional specification - RF coaxial connectors with inner diameter of outer conductor 7 mm (0,276 in) with screw coupling - Characteristics impedance 50 ohms (75 ohms) (type N)

IEC 61169-16:2006

Radio-frequency connectors - Part 16: Sectional specification - RF coaxial connectors with inner diameter of outer conductor 7 mm (0,276 in) with screw coupling - Characteristics impedance 50 ohms (75 ohms) (type N)

Connecteurs pour fréquences radioélectriques - Partie 16: Spécification intermédiaire - Connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur du conducteur extérieur de 7 mm (0,276 in) à verrouillage à vis - Impédance caractéristique 50 ohms (75 ohms) (type N)

Format
Availability
Price and currency
English PDF
Immediate download
287.22 USD
English Hardcopy
in stock
287.22 USD
Standard number:IEC 61169-16:2006
Released:2006-12-14
Language:English
DESCRIPTION

IEC 61169-16:2006

IEC 61169-16:2006 Provides information and rules for the preparation of Detail Specifications (DS) for pin and socket R.F. coaxial connectors, with screw coupling mechanism, for low to medium power applications. The connector is commonly known as the "type N". Three versions of the 50 characteristic impedance type N connector are included, each version being mateable with each of the others.
