immediate downloadReleased: 2021-06-03
21/30408109 DC BS ISO 3767-5. Tractors, machinery for agriculture and forestry, powered lawn and garden equipment. Symbols for operator controls and other displays Part 5. Symbols for manual portable forestry machines

21/30408109 DC

BS ISO 3767-5. Tractors, machinery for agriculture and forestry, powered lawn and garden equipment. Symbols for operator controls and other displays Part 5. Symbols for manual portable forestry machines

Format
Availability
Price and currency
English Secure PDF
Immediate download
25.88 USD
English Hardcopy
In stock
25.88 USD
Standard number:21/30408109 DC
Pages:13
Released:2021-06-03
Status:Draft for Comment
DESCRIPTION

21/30408109 DC


This standard 21/30408109 DC BS ISO 3767-5. Tractors, machinery for agriculture and forestry, powered lawn and garden equipment. Symbols for operator controls and other displays is classified in these ICS categories:
  • 01.080.20 Graphical symbols for use on specific equipment
  • 65.060.80 Forestry equipment

This document standardizes symbols for use specifically on operator controls and other displays on manual portable forestry machines such as chain saws and brush saws.

NOTE 1

ISO 3767-1 covers common symbols that apply to multiple types of agricultural tractors and machinery, forestry machinery, and powered lawn and garden equipment. ISO 3767-2 covers symbols for agricultural tractors and machinery. ISO 3767-3 covers symbols for powered lawn and garden equipment. ISO 3767-4 covers symbols for forestry machinery.

NOTE 2

ISO 7000 and IEC 60417 can be consulted for additional internationally standardized symbols of potential relevance to manual portable forestry machines.
