BS EN IEC 62271-103:2023

This standard BS EN IEC 62271-103:2023 High-voltage switchgear and controlgear is classified in these ICS categories:

• 29.130.10 High voltage switchgear and controlgear

IEC 62271-103:2021 is applicable to three-phase, alternating current switches and switch-disconnectors for their switching function, having making and breaking current ratings, for indoor and outdoor installations, for rated voltages above 1 kV up to and including 52 kV and for rated frequencies from 162/3 Hz up to and including 60 Hz. This document is also applicable to single-pole switches used on three-phase systems. This second edition cancels and replaces the first edition published in 2011. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - this document has been aligned with IEC 62271-1:2017 and IEC 62271-102:2018; - clarifications regarding the behaviour of the switch during breaking tests regarding current interruption and restrikes have been added; - conditions of the switch after making and breaking tests have been clarified; - a new informative Annex B intended to provide guidance for the calculation of Ief1 and Ief2 has been added; - new rules for the combination of 50 Hz and 60 Hz switching tests have been defined and a new table (Table 7) has been added; - tests with specified TRV have been modified to be in accordance with the practice described in IEC 62271-100; - the behaviour of the switch during breaking tests has been clarified and boundaries for restrike allowance have been defined; - explanations for short-circuit making tests have been added; - vacuum integrity check after mechanical operations has been defined; - all test voltages for single-phase capacitive testing have been grouped under 7.101.7.3.2 and have been confirmed by simulation and calculation.
