immediate downloadReleased: 2013-01-31
BS EN 62271-105:2012 High-voltage switchgear and controlgear Alternating current switch-fuse combinations for rated voltages above 1 kV up to and including 52 kV

BS EN 62271-105:2012

High-voltage switchgear and controlgear Alternating current switch-fuse combinations for rated voltages above 1 kV up to and including 52 kV

Format
Availability
Price and currency
English PDF
Immediate download
336.47 USD
English Hardcopy
In stock
336.47 USD
Standard number:BS EN 62271-105:2012
Pages:56
Released:2013-01-31
ISBN:978 0 580 70970 8
Status:Standard
DESCRIPTION

BS EN 62271-105:2012


This standard BS EN 62271-105:2012 High-voltage switchgear and controlgear is classified in these ICS categories:
  • 29.130.10 High voltage switchgear and controlgear
IEC 62271-105:2012 applies to three-pole units for public and industrial distribution systems which are functional assemblies of switches including switch-disconnectors and current-limiting fuses designed so as to be capable of
- breaking, at the rated recovery voltage, any current up to and including the rated short-circuit breaking current;
- making, at the rated voltage, circuits to which the rated short-circuit breaking current applies.
It does not apply to fuse-circuit-breakers, fuse-contactors, combinations for motor-circuits or to combinations incorporating single capacitor bank switches. This second edition cancels and replaces the first edition of IEC 62271-105, published in 2002, and constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- implementation of figures at the place where they are cited first;
- renumbering of tables;
- addition of some of the proposals from IEC paper 17A/852/INF;
- addition of missing subclauses of IEC 62271-1;
- implementation of 6.105 "Extension of validity of type tests" and consequently removing of the relevant parts in the different existing clauses;
- change of 7th paragraph of 6.101.4 as there is now a definition of NSDD given in 3.7.4 of IEC 62271-1:2007. Harmonization with IEC 62271-107;
- some referenced clauses in other standards like IEC 60282-1 were changed and therefore changed the editions under 1.2 to the ones referred to;
- addition of a new Annex C defining tolerances.

This publication is to be read in conjunction with IEC 62271-1:2007.
