BS ISO 128-44:2001

This standard BS ISO 128-44:2001 Technical drawings. General principles of presentation is classified in these ICS categories:

• 01.100.20 Mechanical engineering drawings

This part of ISO 128 specifies general principles for presenting sections on mechanical engineering drawings following the orthographic projection methods specified in ISO 5456-2. For areas on sections, representation is according to ISO 128-50^[1].

Attention has also been given to the requirements of reproduction, including microcopying in accordance with ISO 6428.

NOTE The basic rules for cuts and sections are given in ISO 128-40^[2].
