BS EN 60603-7-2:2009 Connectors for electronic equipment Detail specification for 8-way, unshielded, free and fixed connectors, for data transmissions with frequencies up to 100 MHz

BS EN 60603-7-2:2009

Connectors for electronic equipment Detail specification for 8-way, unshielded, free and fixed connectors, for data transmissions with frequencies up to 100 MHz

CURRENCY
376.8 EUR
Standard number:BS EN 60603-7-2:2009
Pages:84
Released:2010-01-31
ISBN:978 0 580 53763 9
Status:Standard
DESCRIPTION

BS EN 60603-7-2:2009


This standard BS EN 60603-7-2:2009 Connectors for electronic equipment is classified in these ICS categories:
  • 31.220.10 Plug-and-socket devices. Connectors

This part of IEC 60603-7 covers 8-way, unshielded, free and fixed connectors, and specifies mechanical and environmental requirements, and electrical transmission requirements for frequencies up to 100 MHz. These connectors are typically used as category 5 connectors in class D cabling systems specified in ISO/IEC 11801:2002.

These connectors are intermateable, interoperable, and backward compatible with other IEC 60603-7 series connectors. While the definition of interoperable is being discussed within IEC, “interoperable” in this standard means the following: The fixed and the free connector are capable of interconnecting with any IEC 60603-7 series connector, and that when it is interconnected, it fully meets all requirements of the lower frequency IEC 60603-7 series standard.

NOTE Transmission performance categories: in this part of IEC 60603-7, the term “category”, when used in reference to transmission performance, refers to those categories defined by ISO/IEC 11801:2002.
