BS EN 61557-9:2009

This standard BS EN 61557-9:2009 Electrical safety in low voltage distribution systems up to 1000 V a.c. and 1500 V d.c.. Equipment for testing, measuring or monitoring of protective measures is classified in these ICS categories:

• 29.080.01 Electrical insulation in general
• 25.040.40 Industrial process measurement and control
• 17.220.20 Measurement of electrical and magnetic quantities

IEC 61557-9:2009 specifies the requirements for insulation fault location systems which localize insulation faults in any part of the system in unearthed IT a.c. systems and unearthed IT a.c. systems with galvanically connected d.c. circuits having nominal voltages up to 1 000 V a.c., as well as in unearthed IT d.c. systems with voltages up to 1 500 V d.c., independent of the measuring principle. This second edition cancels and replaces the first edition published in 1999. It is a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- scope, normative references and terms and definitions complemented;
- revision of requirements, marking and operating instructions and Clause 6;
- revision of Table 1;
- addition of Annexes A, B and C.
