BS ISO 3245:2015 Rolling bearings. Needle roller bearings with drawn cup and without inner ring. Boundary dimensions, geometrical product specifications (GPS) and tolerance values

BS ISO 3245:2015

Rolling bearings. Needle roller bearings with drawn cup and without inner ring. Boundary dimensions, geometrical product specifications (GPS) and tolerance values

CURRENCY
180 EUR
Standard number:BS ISO 3245:2015
Pages:22
Released:2016-01-31
ISBN:978 0 580 77620 5
Status:Standard
DESCRIPTION

BS ISO 3245:2015


This standard BS ISO 3245:2015 Rolling bearings. Needle roller bearings with drawn cup and without inner ring. Boundary dimensions, geometrical product specifications (GPS) and tolerance values is classified in these ICS categories:
  • 17.040.40 Geometrical Product Specification (GPS)
  • 21.100.20 Rolling bearings

This International Standard specifies the boundary dimensions and preferred dimensions to be used for drawn cup needle roller bearings without inner ring as well as the minimum chamfer dimension limits. Also specified are the closed end thickness dimensions for bearings with one closed end.

In addition, dimensional tolerances for the needle roller complement bore diameter and tolerances for the drawn cup width are specified.

Informative values for the tolerances for shaft raceway and housing bore are given in Annex A.
