PD IEC TR 62001-4:2021

This standard PD IEC TR 62001-4:2021 High-voltage direct current (HVDC) systems. Guidance to the specification and design evaluation of AC filters is classified in these ICS categories:

• 29.200 Rectifiers. Converters. Stabilized power supply

This part of IEC TR 62001, which is a Technical Report, provides guidance on the basic data of AC side filters for high-voltage direct current (HVDC) systems and their components such as ratings, power losses, design issues and special applications, protection, seismic requirements, equipment design and test parameters.

This document covers AC side filtering for the frequency range of interest in terms of harmonic distortion and audible frequency disturbances. It excludes filters designed to be effective in the power line carrier (PLC) and radio interference spectra.

It concerns the conventional AC filter technology and LCC (line-commutated converter) HVDC but much of this applies to any filter equipment for VSC (voltage sourced converter) HVDC.
