BS EN 2997-004. Aerospace series. Connectors, electrical, circular, coupled by threaded ring, fire-resistant or non fire-resistant, operating temperatures - 65 °C to 175 °C continuous, 200 °C continuous, 260 °C peak Part 004. Jam-nut mounted receptacle - Product standard
CURRENCY
Standard number:
22/30454742 DC
Pages:
14
Released:
2022-04-28
Status:
Draft for Comment
DESCRIPTION
22/30454742 DC
This standard 22/30454742 DC BS EN 2997-004. Aerospace series. Connectors, electrical, circular, coupled by threaded ring, fire-resistant or non fire-resistant, operating temperatures - 65 °C to 175 °C continuous, 200 °C continuous, 260 °C peak is classified in these ICS categories:
49.060 Aerospace electric equipment and systems
This document specifies the characteristics of jam-nut mounted receptacles in the family of circular electrical connectors coupled by threaded ring. It applies to the class defined in Table 4. For contacts, filler plugs, and rear accessories associated with this receptacle, see EN 2997-002. For plugs and protective covers, see EN 2997-008 and EN 2997-009 respectively. For spare jam-nuts and o-rings, see EN 2997-012 and EN 2997-013 respectively.
