BS EN 14620-4:2025 - Insulation Components for Refrigerated, Liquefied Gas Storage Tanks

Introducing the BS EN 14620-4:2025, a comprehensive standard that sets the benchmark for the design and manufacture of site-built, vertical, cylindrical, flat-bottomed tank systems. These tanks are specifically engineered for the storage of refrigerated, liquefied gases, with operating temperatures ranging from 0 °C to an extreme -196 °C. This standard is an essential resource for professionals in the field of cryogenic storage, ensuring safety, efficiency, and reliability in the storage of liquefied gases.

Key Features and Benefits

• Comprehensive Guidelines: The standard provides detailed guidelines on the design and manufacture of tank systems, ensuring that all components meet the highest safety and performance standards.
• Temperature Range: Specifically designed to accommodate a wide range of operating temperatures, from 0 °C to -196 °C, making it suitable for various types of liquefied gases.
• Insulation Components: Focuses on the critical insulation components necessary for maintaining the integrity and efficiency of the storage system.
• Industry Compliance: Adheres to the latest industry standards, ensuring compliance and facilitating international trade and cooperation.

Technical Specifications

Standard Number	BS EN 14620-4:2025
Pages	40
Release Date	May 2, 2025
ISBN	978 0 539 21457 4
Status	Standard

Why Choose BS EN 14620-4:2025?

The BS EN 14620-4:2025 standard is an indispensable tool for engineers, designers, and manufacturers involved in the construction and maintenance of cryogenic storage tanks. By adhering to this standard, you ensure that your storage systems are not only compliant with the latest safety regulations but also optimized for performance and durability.

With the increasing demand for liquefied gases in various industries, from energy to healthcare, the need for reliable and efficient storage solutions has never been greater. The BS EN 14620-4:2025 standard provides the framework necessary to meet these demands, offering peace of mind and assurance of quality.

Applications

This standard is applicable to a wide range of industries that require the storage of refrigerated, liquefied gases. These include:

• Energy Sector: For the storage of liquefied natural gas (LNG) and other energy-related gases.
• Healthcare: For the storage of medical gases used in various treatments and procedures.
• Manufacturing: In processes that require the use of liquefied gases as raw materials or coolants.
• Food and Beverage: For the preservation and processing of food products using liquefied gases.

Conclusion

The BS EN 14620-4:2025 standard is a vital resource for anyone involved in the design, manufacture, and operation of cryogenic storage tanks. Its comprehensive guidelines and focus on insulation components ensure that your storage systems are safe, efficient, and compliant with the latest industry standards. Invest in the BS EN 14620-4:2025 standard to enhance the reliability and performance of your storage solutions, and stay ahead in the competitive landscape of liquefied gas storage.

BS EN 14620-4:2025

This standard BS EN 14620-4:2025 Design and manufacture of site built, vertical, cylindrical, flat-bottomed tank systems for the storage of refrigerated, liquefied gases with operating temperatures between 0 °C and -196 °C is classified in these ICS categories:

• 23.020.10 Stationary containers and tanks

This document specifies the requirements for materials, design and installation of the insulation of refrigerated liquefied gas (RLG) storage tank systems. RLG storage tank systems store liquefied gas with a low boiling point, i.e. below normal ambient temperature. The concept of storing such products in liquid form and in non-pressurized tanks therefore depends on the combination of latent heat of vaporization and thermal insulation. Consequently, thermal insulation for RLG storage tank systems is not an ancillary part of the containment system (as for most ambient atmospheric hydrocarbon tanks) but it is an essential component and the storage tank system cannot operate without a properly designed, installed and maintained insulation system. The main functions of the insulation in RLG storage tank systems are: - to maintain the boil off due to heat in-leak at or below the specified limits; - to limit the thermal loading of the outer tank components, so to prevent both their sudden damage and premature ageing (e.g. due to external condensation and ice formation); - to prevent damage by frost heave of the foundation/soil beneath the tank base slab (in combination with the slab heating system for tanks resting at grade); - to minimize condensation and icing on the outer surfaces of the tank. A wide range of insulation materials is available. However, the material properties differ greatly amongst the various generically different materials and also within the same generic group of materials. Therefore, within the scope of this document, only general guidance on selection of materials is given. NOTE For general guidance on selection of materials, see Annex A. This document deals with the design and manufacture of site built, vertical, cylindrical, flat-bottomed tank systems for the storage of refrigerated, liquefied gases with operating temperatures between 0 °C and −196 °C.
