BS EN 4604-008:2025 Aerospace Series Coaxial Cable

Introducing the BS EN 4604-008:2025, a cutting-edge product standard that sets the benchmark for electrical cables used in aerospace applications. This standard is specifically designed for coaxial cables used in signal transmission, ensuring optimal performance and reliability in demanding environments.

Product Overview

The BS EN 4604-008:2025 standard is a comprehensive guide for the design and application of coaxial cables with a characteristic impedance of 50 ohms. These cables are engineered to withstand temperatures up to 200 °C, making them ideal for high-temperature aerospace environments. The Type WD designation indicates a specific construction and performance criteria that meet the rigorous demands of the aerospace industry.

Key Features

• Standard Number: BS EN 4604-008:2025
• Pages: 20
• Release Date: August 21, 2025
• ISBN: 978 0 539 29917 5
• Status: Standard

Why Choose BS EN 4604-008:2025?

The aerospace industry demands the highest standards of quality and reliability, and the BS EN 4604-008:2025 standard delivers on these expectations. Here are some reasons why this standard is the preferred choice for aerospace signal transmission cables:

• High Temperature Resistance: With a maximum operating temperature of 200 °C, these cables are designed to perform in extreme conditions, ensuring signal integrity and reliability.
• Precision Engineering: The 50-ohm impedance is meticulously maintained to provide consistent signal transmission, minimizing loss and interference.
• Industry Compliance: As a recognized standard, it ensures compliance with international aerospace requirements, facilitating global interoperability and acceptance.
• Durability: The Type WD construction offers enhanced durability, making it suitable for the rigorous demands of aerospace applications.

Applications

The BS EN 4604-008:2025 standard is applicable to a wide range of aerospace applications, including:

• Avionics systems
• Communication systems
• Navigation systems
• Data transmission networks

Technical Specifications

Understanding the technical specifications of the BS EN 4604-008:2025 standard is crucial for its application in aerospace projects. Here are some of the key technical details:

• Impedance: 50 ohms
• Temperature Rating: Up to 200 °C
• Type: WD (specific construction and performance criteria)

Conclusion

The BS EN 4604-008:2025 standard represents the pinnacle of coaxial cable design for aerospace applications. Its robust construction, high-temperature resistance, and compliance with international standards make it an indispensable component in the aerospace industry. Whether you are involved in the design, manufacturing, or maintenance of aerospace systems, this standard provides the assurance of quality and performance that you need.

For those seeking a reliable and efficient solution for signal transmission in aerospace environments, the BS EN 4604-008:2025 is the definitive choice. Embrace the future of aerospace technology with a standard that is engineered to meet the challenges of tomorrow.

BS EN 4604-008:2025

This standard BS EN 4604-008:2025 Aerospace series. Cable, electrical, for signal transmission is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This document specifies the required characteristics of a coaxial cable, 50 Ω, type WD, for use in aircraft electrical systems at operating temperature between -55 °C and 200 °C and specially for high frequency up to 6 GHz. Nevertheless, if needed, −65 °C is also acceptable as shown by thermal stability test.
