BS EN 50399:2011+A1:2016
Common test methods for cables under fire conditions. Heat release and smoke production measurement on cables during flame spread test. Test apparatus, procedures, results
| Standard number: | BS EN 50399:2011+A1:2016 |
| Pages: | 62 |
| Released: | 2016-07-31 |
| ISBN: | 978 0 580 91574 1 |
| Status: | Standard |
BS EN 50399:2011+A1:2016
This standard BS EN 50399:2011+A1:2016 Common test methods for cables under fire conditions. Heat release and smoke production measurement on cables during flame spread test. Test apparatus, procedures, results is classified in these ICS categories:
- 29.060.20 Cables
- 13.220.40 Ignitability and burning behaviour of materials and products
EN 50399 specifies the apparatus and methods of test for the assessment of vertical flame spread, heat release, smoke production and occurrence of flaming droplets/particles of vertically-mounted bunched wires or cables, electrical or optical, under defined conditions.
For the purpose of this standard the term "electric wire or cable" covers all insulated metallic conductor cables used for the conveyance of energy or signals.
EN 50399 details the apparatus and the arrangement and calibration of the instrumentation to be installed in order to measure the heat release and the smoke production during the test. The combustion gases are collected in a hood above the test chamber and conveyed through an exhaust system, which allows the measurement of heat release rate and smoke production. Test procedures to be used for type approval testing for classification of cables in Euroclasses B1 ca, B2 ca, C ca and D ca are given. Cable installation on the test ladder and the volume of air passing through the chamber are in accordance with the Commission Decision 2006/751/EC [2] which is reflected in the requirements of this standard.
The apparatus described in this standard shall be used in conjunction with that described in EN 60332‑3‑10 .
