Industrial communication networks. Fieldbus specifications Physical layer specification and service definition
CURRENCY
Standard number:
BS EN 61158-2:2014
Pages:
480
Released:
2014-10-31
ISBN:
978 0 580 79255 7
Status:
Standard
DESCRIPTION
BS EN 61158-2:2014
This standard BS EN 61158-2:2014 Industrial communication networks. Fieldbus specifications is classified in these ICS categories:
35.100.20 Data link layer
25.040.40 Industrial process measurement and control
35.100.10 Physical layer
35.240.50 IT applications in industry
IEC 61158-2:2014 specifies the requirements for fieldbus component parts. It also specifies the media and network configuration requirements necessary to ensure agreed levels of data integrity before data-link layer error checking and interoperability between devices at the physical layer. The fieldbus physical layer conforms to layer 1 of the OSI 7-layer model as defined by ISO 7498 with the exception that, for some types, frame delimiters are in the physical layer while for other types they are in the data-link layer. This sixth edition cancels and replaces the fifth edition published in 2010. It constitutes a technical revision. This edition includes the following changes: - new Type 20 specification; - new Type 24 specification; - RS232 media specification for Type 4 removed.
