Electronic design interchange format (EDIF) Part 1: Version 3 0 0; Part 2: Version 4 0 0 (CD-ROM)
Format
Availability
Price and currency
English Secure PDF
Immediate download
379.50 EUR
English Hardcopy
In stock
379.50 EUR
Standard number:
BS EN 61690-1/2:2000
Released:
2000-12-15
ISBN:
0 580 36807 6
Status:
Standard
DESCRIPTION
BS EN 61690-1/2:2000
This standard BS EN 61690-1/2:2000 Electronic design interchange format (EDIF) is classified in these ICS categories:
35.240.50 IT applications in industry
35.080 Software
IEC 61690-1:2000 defines the syntax and semantics for EDIF Version 3 0 0. EDIF Version 3 0 0 addresses EDIF Level 0 and Level 1. EDIF Version 3 0 0 completely addresses the Connectivity and Schematic views, including at Level 1 the ability to represent frames. It includes capabilities formerly found in the Document and Graphics views. A series of releases is planned in the near future to address those views not completely addressed in this version.
