BS EN 62196-2:2017 - TC Tracked Changes. Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles Dimensional compatibility and interchangeability requirements for a.c. pin and contact-tube accessories

BS EN 62196-2:2017 - TC

Tracked Changes. Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles Dimensional compatibility and interchangeability requirements for a.c. pin and contact-tube accessories

Format
Availability
Price and currency
English Secure PDF
Immediate download
524.96 USD
English Hardcopy
In stock
524.96 USD
Standard number:BS EN 62196-2:2017 - TC
Released:2020-02-25
ISBN:978 0 539 09013 0
Status:Tracked Changes
DESCRIPTION

BS EN 62196-2:2017 - TC


This standard BS EN 62196-2:2017 - TC Tracked Changes. Plugs, socket-outlets, vehicle connectors and vehicle inlets. Conductive charging of electric vehicles is classified in these ICS categories:
  • 29.120.30 Plugs, socket-outlets, couplers
  • 43.120 Electric road vehicles
IEC 62196-2:2016 applies to plugs, socket-outlets, vehicle connectors and vehicle inlets with pins and contact-tubes of standardized configurations, herein referred to as accessories. They have a nominal rated operating voltage not exceeding 480 V a.c., 50 Hz to 60 Hz, and a rated current not exceeding 63 A three-phase or 70 A single phase, for use in conductive charging of electric vehicles. This second edition cancels and replaces the first edition published in 2011 and constitutes a technical revision. This second edition includes the following significant technical changes with respect to the previous edition.
a) Standard sheets for configurations type 2 and type 3 have been updated.
b) Configuration type 2 is now available with optional shutter.

This publication is to be read in conjunction with IEC 62196-1:2014.
