BS EN 9300-100:2018 Aerospace series. LOTAR. Long Term Archiving and Retrieval of digital technical product documentation such as 3D, CAD and PDM data Common concepts for Long term archiving and retrieval of CAD 3D mechanical information

BS EN 9300-100:2018

Aerospace series. LOTAR. Long Term Archiving and Retrieval of digital technical product documentation such as 3D, CAD and PDM data Common concepts for Long term archiving and retrieval of CAD 3D mechanical information

Format
Availability
Price and currency
English Secure PDF
Immediate download
360.89 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
36.09 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
108.27 USD
English Hardcopy
In stock
360.89 USD
Standard number:BS EN 9300-100:2018
Pages:62
Released:2018-07-19
ISBN:978 0 580 63777 3
Status:Standard
DESCRIPTION

BS EN 9300-100:2018


This standard BS EN 9300-100:2018 Aerospace series. LOTAR. Long Term Archiving and Retrieval of digital technical product documentation such as 3D, CAD and PDM data is classified in these ICS categories:
  • 49.020 Aircraft and space vehicles in general
  • 35.240.30 IT applications in information, documentation and publishing
  • 35.240.10 Computer-aided design (CAD)
  • 01.110 Technical product documentation
1.1 Introduction This European Standard defines common fundamental concepts for Long Term Archiving and Retrieval of CAD mechanical information for elementary parts and assemblies. It details the "fundamentals and concepts" of EN 9300-003 in the specific context of Long Term Archiving of CAD mechanical models. CAD mechanical information is divided into assembly structure and geometrical information, both including explicit and implicit geometrical representation, Geometric Dimensioning and Tolerancing with Form Features. The EN 9300-1XX family is organized as a sequence of parts, each building on the previous in a consistent way, each adding a level of complexity in the CAD data model. This includes the detailing of relationships between the essential information for the different types of CAD information covered by the EN 9300-1XX family. As technology matures additional parts will be released in order to support new requirements within the aerospace community. 1.2 In scope The present part describes: - the fundamentals and concepts for Long Term Archiving and Retrieval of CAD 3D mechanical information; - the document structure of the EN 9300-1XX family, and the links between all these parts; - the qualification methods for long term preservation of archived CAD mechanical information; more specially, principles for the CAD validation properties and for verification of the quality of the CAD archived file; - specifications for the preservation planning of archived CAD information; - specific functions for administration and monitoring of CAD archived mechanical models; - the definition of Archive Information Packages for CAD data. 1.3 Out of Scope The following are out of scope for this part: - Long Term Archiving of CAD 2D drawings; - other CAD business disciplines, such as piping, tubing, electrical harnesses, composite, sheet metal design, kinematics. This version does not include: - fundamental and concepts for parts EN 9300-120 version 2, EN 9300-125, 1 EN 9300-130.
