BS EN ISO 8062-3:2023 - TC Tracked Changes. Geometrical product specifications (GPS). Dimensional and geometrical tolerances for moulded parts General dimensional and geometrical tolerances and machining allowances for castings using ± tolerances for indicated dimensions

BS EN ISO 8062-3:2023 - TC

Tracked Changes. Geometrical product specifications (GPS). Dimensional and geometrical tolerances for moulded parts General dimensional and geometrical tolerances and machining allowances for castings using ± tolerances for indicated dimensions

Format
Availability
Price and currency
English Secure PDF
Immediate download
413.40 USD
English Hardcopy
In stock
413.40 USD
Standard number:BS EN ISO 8062-3:2023 - TC
Pages:102
Released:2023-03-06
ISBN:978 0 539 26209 4
Status:Tracked Changes
DESCRIPTION

BS EN ISO 8062-3:2023 - TC


This standard BS EN ISO 8062-3:2023 - TC Tracked Changes. Geometrical product specifications (GPS). Dimensional and geometrical tolerances for moulded parts is classified in these ICS categories:
  • 01.040.17 Metrology and measurement. Physical phenomena (Vocabularies)
  • 17.040.40 Geometrical Product Specification (GPS)
  • 01.040.77 Metallurgy (Vocabularies)
  • 17.040.10 Limits and fits
  • 77.140.80 Iron and steel castings
This document specifies general dimensional and geometrical tolerances as well as machining allowance grades for castings using ± tolerances for indicated dimensions as delivered to the purchaser according to ISO/TS 8062-2. It is applicable for tolerancing of dimensions and geometry of castings in all cast metals and their alloys produced by various casting manufacturing processes. This document does not apply to 3D CAD models used without indicated dimensions. This document applies to both general dimensional and general geometrical tolerances (referred to in or near the title block of the drawing), unless otherwise specified and where specifically referred to on the drawing by one of the references in Clause 11. The dimensional tolerances covered by this document are tolerances for linear dimensions. The geometrical tolerances covered by this document are tolerances for: —     straightness; —      flatness; —     roundness; —     parallelism; —     perpendicularity; —     symmetry; —     coaxiality. This document does not cover other position tolerances, angular dimensional tolerances or cylindricity tolerances. This document can be used for the selection of tolerance values for individual indications.
