>BSI Standards >23 FLUID SYSTEMS AND COMPONENTS FOR GENERAL USE>23.100 Fluid power systems>23.100.20 Cylinders>BS ISO 15552:2018 Pneumatic fluid power. Cylinders with detachable mountings, 1 000 kPa (10 bar) series, bores from 32 mm to 320 mm. Basic, mounting and accessories dimensions
immediate downloadReleased: 2018-04-13
BS ISO 15552:2018 Pneumatic fluid power. Cylinders with detachable mountings, 1 000 kPa (10 bar) series, bores from 32 mm to 320 mm. Basic, mounting and accessories dimensions

BS ISO 15552:2018

Pneumatic fluid power. Cylinders with detachable mountings, 1 000 kPa (10 bar) series, bores from 32 mm to 320 mm. Basic, mounting and accessories dimensions

Format
Availability
Price and currency
English Secure PDF
Immediate download
Printable - You are authorized to print 1 copy
246.40 EUR
English Hardcopy
In stock
246.40 EUR
Standard number:BS ISO 15552:2018
Pages:28
Released:2018-04-13
ISBN:978 0 580 91823 0
Status:Standard
DESCRIPTION

BS ISO 15552:2018


This standard BS ISO 15552:2018 Pneumatic fluid power. Cylinders with detachable mountings, 1 000 kPa (10 bar) series, bores from 32 mm to 320 mm. Basic, mounting and accessories dimensions is classified in these ICS categories:
  • 23.100.20 Cylinders

This document establishes a metric series of basic, mounting and accessories dimensions as required for interchangeability of single or double rod pneumatic cylinders with or without provision for magnetic sensors for a maximum rated pressure of 1 000 kPa (10 bar).

It applies to pneumatic cylinders with detachable mountings.
