immediate downloadReleased: 1985-01-01
IEC 60169-20:1985
Radio-frequency connectors. Part 20: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) screw coupling. Characteristic impedance 50 ohms (Type SSMC)
Connecteurs pour fréquences radioélectriques. Vingtième partie: Connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur de conducteur extérieur de 2,08 mm (0,082 in) à verrouillage à vis. Impédance caractéristique 50 ohms (type SSMC)
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
Printable
21.60 EUR
English/French - Bilingual Hardcopy
in stock
21.60 EUR
| Standard number: | IEC 60169-20:1985 |
| Released: | 1985-01-01 |
| Edition: | 1 |
| ICS: | 33.120.30 |
| Pages (English/French - Bilingual): | 15 |
| ISBN (English/French - Bilingual): | 2831811066 |
DESCRIPTION
IEC 60169-20:1985
Provides basic mating and performance information for a subminiature coaxial connector for use with flexible and semi-rigid r.f. cables. The connectors are usable up to a frequency of 6 GHz. Only the interface dimensions are standardized. Other technical data are supplied for guidance only.
