IEC 60679-3:2012
Quartz crystal controlled oscillators of assessed quality - Part 3: Standard outlines and lead connections
Oscillateurs pilotés par quartz sous assurance de la qualité - Partie 3: Encombrements normalisés et connexions des sorties
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
Printable
167.40 EUR
English/French - Bilingual Hardcopy
in stock
167.40 EUR
| Standard number: | IEC 60679-3:2012 |
| Released: | 2012-12-14 |
| Edition: | 3 |
| ICS: | 31.140 |
| Pages (English/French - Bilingual): | 49 |
| ISBN (English/French - Bilingual): | 9782832205693 |
DESCRIPTION
IEC 60679-3:2012
IEC 60679-3:2012 specifies the outline dimensions and lead connections for quartz crystal controlled oscillators with lead enclosures. This edition includes the following significant technical changes with respect to the previous edition:
- CO 01, CO 07, CO 10, CO 17 and CO 18 were deleted;
- The current pin layout of CO 06 was deleted. And new pin layout of CO 06 was added as CO 40;
- New layout of CO 15 was added as CO 41;
- Two new enclosures, CO 42 and CO 43 were added. Therefore revised edition includes 15 types of enclosures as in Table 1 of Clause 5.
