IEC 61169-10:2024
Radio-frequency connectors - Part 10: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 3 mm (0,12 in) with snap-on coupling - Characteristic impedance 50 Ω (Type SMB)
Connecteurs pour fréquences radioélectriques - Partie 10: Spécification intermédiaire relative aux connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur du conducteur extérieur de 3 mm (0,12 in) à couplage par encliquetage - Impédance caractéristique 50 Ω (type SMB)
| Standard number: | IEC 61169-10:2024 |
| Released: | 2024-02-22 |
| Edition: | 1 |
| ICS: | 33.120.30 |
| Pages (English/French - Bilingual): | 52 |
| ISBN (English/French - Bilingual): | 9782832282779 |
IEC 61169-10:2024
IEC 61169-10:2024, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for series SMB RF coaxial connectors with snap-on coupling with a characteristic impedance of 50 Ω.
This document prescribes mating face dimensions for high performance connectors – grade 2, dimensional details of standard test connectors − grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series SMB RF connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
The series SMB connectors are used to connect with all kinds of RF cables and microstrips in microwave transmission systems. The operating frequency is up to 4 GHz.
