Homepage>IEC Standards>IEC 61169-23:2025 - Radio-frequency connectors - Part 23: Pin and socket connector for use with 3,5 mm rigid precision coaxial lines with inner diameter of outer conductor of 3,5 mm (0,1378 in)
download between 0-24 hoursReleased: 2025-08-27

IEC 61169-23:2025

Radio-frequency connectors - Part 23: Pin and socket connector for use with 3,5 mm rigid precision coaxial lines with inner diameter of outer conductor of 3,5 mm (0,1378 in)

Connecteurs pour fréquences radioélectriques - Partie 23: Connecteur mâle et connecteur femelle pour lignes coaxiales rigides de précision de 3,5 mm avec diamètre intérieur du conducteur extérieur de 3,5 mm (0,1378 in)

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
167.40 EUR
English/French - Bilingual Hardcopy
in stock
167.40 EUR
Standard number:IEC 61169-23:2025
Released:2025-08-27
Edition:1
ICS:33.120.30
Pages (English/French - Bilingual):45
ISBN (English/French - Bilingual):9782832706657
DESCRIPTION

IEC 61169-23:2025

IEC 61169-23:2025, which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for pin and socket connector for use with 3,5 mm rigid precision coaxial lines with inner diameter of outer conductor 3,5 mm (0,137 8 in).
This document specifies mating face dimensions for high performance connectors – grade 1, dimensional details of standard test connectors – grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series 3,5 mm RF connectors.
This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
These connectors are constructed so as to affix on the 50 Ω, 3,5 mm rigid precision coaxial line described in IEC 60457-5, and to provide low reflection to 34 GHz. These connectors can be intermated with SMA (IEC 61169-15) and 2,92 mm (IEC 61169-35) connectors.
