IEC 61188-7:2017
Printed boards and printed board assemblies - Design and use - Part 7: Electronic component zero orientation for CAD library construction
Cartes imprimées et cartes imprimées équipées - Conception et utilisation - Partie 7: Orientation nulle des composants électroniques pour l'élaboration d’une bibliothèque CAO
Format
Availability
Price and currency
English PDF
Immediate download
124.20 EUR
English Hardcopy
in stock
124.20 EUR
English/French - Bilingual PDF
Immediate download
124.20 EUR
| Standard number: | IEC 61188-7:2017 |
| Released: | 2017-04-10 |
| Edition: | 2 |
| ICS: | 31.180 |
| Pages (English): | 20 |
| ISBN (English): | 9782832241653 |
| Pages (English/French - Bilingual): | 40 |
| ISBN (English/French - Bilingual): | 9782832273883 |
DESCRIPTION
IEC 61188-7:2017
IEC 61188-7:2017 establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.
This edition includes the following significant technical changes with respect to the previous edition:
a) Figure 1 has been corrected;
b) the term “rectangle” has generally been replaced by “polygon”;
c) level B has been indicated as preferred level for new libraries.
