IEC 61189-2-808:2024
Test methods for electrical materials, printed board and other interconnection structures and assemblies - Part 2-808: Thermal resistance of an assembly by thermal transient method
Méthodes d'essai pour les matériaux électriques, les cartes imprimées et autres structures et assemblages d'interconnexion - Partie 2-808 : Résistance thermique d'un assemblage par la méthode du transitoire thermique
| Standard number: | IEC 61189-2-808:2024 |
| Released: | 2024-04-25 |
| Edition: | 1 |
| ICS: | 31.180 |
| Pages (English/French - Bilingual): | 40 |
| ISBN (English/French - Bilingual): | 9782832288047 |
IEC 61189-2-808:2024
IEC 61189-2-808:2024 describes the thermal transient method to characterize the thermal resistance of an assembly consisting of a heat source (e.g. power device), an attachment material (e.g. solder) and a dielectric layer with electrode. This method is suitable to determine the thermal resistance of materials and assembly methods as well as to optimize the thermal flux to a heat sink.
NOTE: This method is not intended to measure and specify the value of the thermal resistance of a dielectric material. For that purpose, other standards exist. Examples are given in Annex A.
