IEC 61784-2:2019
Industrial communication networks - Profiles - Part 2: Additional fieldbus profiles for real-time networks based on ISO/IEC/IEEE 8802-3
Réseaux de communication industriels - Profils - Partie 2 : Profils de bus de terrain supplémentaires pour les réseaux en temps réel fondés sur l’ISO/IEC/IEEE 8802-3
Standard number: | IEC 61784-2:2019 |
Released: | 2019-04-10 |
Language: | English |
IEC 61784-2:2019
IEC 61784-2:2019 specifies the performance indicators supporting classification schemes for Real-Time Ethernet (RTE) requirements; the profiles and related network components based on ISO/IEC 8802-3 or IEEE 802.3, IEC 61158 series, and IEC 61784-1 and the RTE solutions that are able to run in parallel with ISO/IEC 8802-3 or IEEE 802.3 based applications. These communication profiles are called Real-Time Ethernet communication profiles. This fourth edition cancels and replaces the third edition published in 2014 and constitutes a technical revision. The main changes are: • update of reference from ISO/IEC 8802-3 to ISO/IEC/IEEE 8802-3; • update of the dated references to the IEC 61158 series, to IEC 61784 1, to the IEC 61784-5 series and to IEC 61918 throughout the document; • update of selection tables for CPF 2, CPF 3, CPF 4, CPF 8 and CPF 17; • CPF3: update of the requirements for all conformance classes; • CPF3: updated timing requirements for IO devices; • CPF3: refining the added application classes; • addition of a new Communication Profile Family – CPF 20 in Clause 21; • addition of a new Communication Profile Family – CPF 21 in Clause 22
