IEC TR 62316:2017
Guidance for the interpretation of OTDR backscattering traces for single-mode fibres
| Standard number: | IEC TR 62316:2017 |
| Released: | 2017-07-12 |
| Edition: | 3 |
| ICS: | 33.180.10 |
IEC TR 62316:2017
IEC/TR 62316:2017 which is a Technical Report, aims to provide guidelines for the interpretation of backscattering traces, as obtained by traditional optical time domain reflectometers (OTDRs) – not including polarization OTDRs – for single-mode fibres. Also, backscattered power effects are discussed in case of unidirectional trace. Full description of the test measurement procedure can be found in Annex C of IEC 60793-1-40:2001. This third edition cancels and replaces the second edition published in 2007. It constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a. the scope has been extended to include single-mode fibres;
b. backscattered power effects are discussed in case of unidirectional trace, including so-called losers and gainers.
c. example of apparent splice loss evaluation for unidirectional OTDR measurements has been added:
d. description of launch and tail cords have been added;
e. figures have been improved.
