This document specifies the mounting dimensions of the accessories regarding interchangeability for 16 MPa (160 bar) compact cylinders conforming to ISO 6020-3. The accessories are applied to mounting with cylinders manufactured in accordance with ISO 6020-3.

This document covers the following accessories of which the identification code is specified in ISO 6099:

• AP2 rod clevis, internal thread (see Figure 1 and Table 1);
• AP4 rod eye, plain, internal thread (see Figure 2 and Table 2);
• AA4 - L pivot pin (locking plate) (see Figure 3 and Table 3);
• AL6 locking plate for pivot pin (see Figure 4 and Table 4);
• AA4 - S and AA4 - R pivot pin plain (see Figure 5-6 and Table 5 respectively).

The design of these accessories is based on the maximum forces derived from pressures and bore diameters of the cylinders specified in ISO 2944 and ISO 3320.
