ISO 5686-3:2024
ISO 5686-3:2024-Polygonal turret interface with flat contact surface — Part 3: Coupling for driven tool holders with shanks of type F and A
Format
Availability
Price and currency
English PDF
Immediate download
Printable
70.00 EUR
English Hardcopy
In stock
70.00 EUR
French PDF
Immediate download
Printable
70.00 EUR
French Hardcopy
In stock
70.00 EUR
Standard´s number: | ISO 5686-3:2024 |
Pages: | 6 |
Edition: | 1 |
Released: | 2024 |
DESCRIPTION
ISO 5686-3:2024
This document specifies the dimensions of couplings for driven tool holders with polygonal taper shanks with flat contact surface (PTI). These shanks are the tool-side part of the interface to the (in cutting process non-rotating) tool carrier of machine tools (e.g. turret lathes, turning centres). This document specifies a coupling type that applies to two of the three tool-side interface types defined in ISO 5686-1 (F, A). The tool shanks themselves are designed identically for all types. — Shank type F has two holes for the coolant supply (F = fluid) on the face contact for use in two installation positions (offset by 180°). — Shank type A has two holes on the face contact for the primary coolant supply and additional two holes for supplying the tool holder (driven tool) with sealing air (A = air). An installation position offset by 180° is possible. A spring-type straight pin belongs to the holder and avoids incorrect insertion.
