>UNE standards>UNE EN 4036:2021 - Aerospace series - Rod end, adjustable, with self-aligning double row ball bearing and threaded shank, in corrosion resisting steel, reduced internal radial clearance - Dimensions and loads (Endorsed by Asociación Española de Normalización in April of 2021.)
in stockReleased: 2021-04-01
UNE EN 4036:2021 - Aerospace series - Rod end, adjustable, with self-aligning double row ball bearing and threaded shank, in corrosion resisting steel, reduced internal radial clearance - Dimensions and loads (Endorsed by Asociación Española de Normalización in April of 2021.)

UNE EN 4036:2021

Aerospace series - Rod end, adjustable, with self-aligning double row ball bearing and threaded shank, in corrosion resisting steel, reduced internal radial clearance - Dimensions and loads (Endorsed by Asociación Española de Normalización in April of 2021.)

Material aeroespacial. Terminales, ajustables con rótulas con doble fila de bolas autoalineables y con vástago roscado en acero resistente a la corrosión, con juego radial reducido. Dimensiones y cargas (Ratificada por la Asociación Española de Normalización en abril de 2021.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
62.70 EUR
English Hardcopy
In stock
62.70 EUR
Standard number:UNE EN 4036:2021
Pages:13
Released:2021-04-01
Status:Standard
DESCRIPTION

UNE EN 4036:2021

This document specifies the characteristics of adjustable rod ends with self-aligning double row ball bearing with reduced internal radial clearance and threaded shank in corrosion resisting steel, designed to withstand only slow rotations and oscillations under load. They consist of: a rod end comprising: circumferential groove to identify location; either seals or shields; an optional longitudinal groove for locking purpose; an inner ring with balls. These rod ends are intended for use with flight control rods or rods for aerospace structures. They are intended to be used in the temperature range: "54 °C to 150 °C. However, being lubricated with the following greases: very high pressure grease, ester type (code A), operational range "73 °C to 121 °C; or very high pressure grease, synthetic hydrocarbons, general purpose (code B), operational range "54 °C to 177 °C (see EN 2067); their field of application when lubricated with code A grease is limited to 121 °C.
