UNE EN 4611-003:2018
Aerospace series - Cables, electrical, for general purpose, single and multicore assembly - XLETFE Family - Part 003: Tin plated copper - Operating temperatures, between -65 °C and 135 °C - Single extruded wall for enclosed applications - UV laser printable - Product standard (Endorsed by Asociación Española de Normalización in February of 2019.)
Material aeroespacial. Cables eléctricos con un conductor y multiconductores para uso general. Familia XLETFE. Parte 003: Cobre estañado. Temperaturas de utilización comprendidas entre -65 °C y 135 °C. Conductor individual aislado para aplicaciones internas. Imprimible con láser UV. Norma de producto. (Ratificada por la Asociación Española de Normalización en febrero de 2019.)
| Standard number: | UNE EN 4611-003:2018 |
| Pages: | 13 |
| Released: | 2019-02-01 |
| Status: | Standard |
UNE EN 4611-003:2018
This European Standard specifies the characteristics of UV laser printable, tin plated copper conductor electrical cables Crosslinked Ethylene Tetra Fluoro Ethylene co-polymer (XLETFE) family for use in the on-board electrical systems of aircraft operating at temperatures between 65 °C and 135 °C. The voltage rating is 600 Vrms at sea level. This insulation system has been used in aerospace applications using 115 Vac (phase-to-neutral) 400 Hz and 28 Vdc. Verification of the suitability of cables for use in other electrical systems is the responsibility of the user. These cables are only suitable for airframe use with additional protection against mechanical abuse. In case of conflict between this standard and other referenced documents the requirements of this standard shall take precedence.
