UNE EN 50069:2018 - High-Voltage Switchgear and Controlgear - Gas-filled welded composite enclosures of cast and wrought aluminium alloys (Endorsed by Asociación Española de Normalización in December of 2018.)

UNE EN 50069:2018

High-Voltage Switchgear and Controlgear - Gas-filled welded composite enclosures of cast and wrought aluminium alloys (Endorsed by Asociación Española de Normalización in December of 2018.)

Aparamenta de alta tensión. Envolventes soldadas de aleación de aluminio con partes fundidas y partes forjadas bajo presión de gas. (Ratificada por la Asociación Española de Normalización en diciembre de 2018.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
70.40 EUR
English Hardcopy
In stock
70.40 EUR
Standard number:UNE EN 50069:2018
Pages:18
Released:2018-12-01
Status:Standard
DESCRIPTION

UNE EN 50069:2018

This European Standard applies to welded composite enclosures of cast and wrought aluminium alloy pressurized with dry air, inert gases (e.g. sulphur hexafluoride or nitrogen or a mixture of such gases), used in indoor and outdoor installations of high-voltage switchgear and controlgear with rated voltages above 1kV, where the gas is used principally for its dielectric and/or arc-quenching properties with rated voltages above 1 kV and up to and including 52 kV and with gas-filled compartments with design pressure higher than 300 kPa relative pressure (gauge); and with rated voltage above 52 kV. The enclosures comprise parts of electrical equipment not necessarily limited to the following examples: circuit-breakers; switch-disconnectors; disconnectors; earthing switches; current transformers; voltage transformers; surge arrestors; busbars and connections; etc. The scope also covers enclosures of pressurized components such as the centre chamber of live tank switchgear, gas-insulated current transformers, etc.
