>UNE standards>UNE EN 61850-7-4:2010/A1:2020 - Communication networks and systems for power utility automation - Part 7-4: Basic communication structure - Compatible logical node classes and data object classes (Endorsed by Asociación Española de Normalización in May of 2020.)
in stockReleased: 2020-05-01
UNE EN 61850-7-4:2010/A1:2020 - Communication networks and systems for power utility automation - Part 7-4: Basic communication structure - Compatible logical node classes and data object classes (Endorsed by Asociación Española de Normalización in May of 2020.)

UNE EN 61850-7-4:2010/A1:2020

Communication networks and systems for power utility automation - Part 7-4: Basic communication structure - Compatible logical node classes and data object classes (Endorsed by Asociación Española de Normalización in May of 2020.)

Sistemas y redes de comunicación para la automatización de las redes de potencia de las compañías eléctricas. Parte 7-4: Estructura de comunicación básica. Clases de datos y nodos lógicos compatibles. (Ratificada por la Asociación Española de Normalización en mayo de 2020.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
462.00 EUR
English Hardcopy
In stock
462.00 EUR
Standard number:UNE EN 61850-7-4:2010/A1:2020
Pages:434
Released:2020-05-01
Status:Amendment
DESCRIPTION

UNE EN 61850-7-4:2010/A1:2020

This part of IEC 61850 specifies the information model of devices and functions generally related to common use regarding applications in systems for power utility automation. It also contains the information model of devices and function-related applications in substations. In particular, it specifies the compatible logical node names and data object names for communication between intelligent electronic devices (IED). This includes the relationship between logical nodes and data objects. The logical node names and data object names defined in this document are part of the class model introduced in IEC 61850-7-1 and defined in IEC 61850-7-2. The names defined in this document are used to build the hierarchical object references applied for communicating with IEDs in systems for power utility automation and, especially, with IEDs in substations and on distribution feeders. The naming conventions of IEC 61850-7-2 are applied in this part. To avoid private, incompatible extensions, this part specifies normative naming rules for multiple instances and private, compatible extensions of logical node (LN) classes and data object names. Any definition is based on IEC 61850 or on referenced well identified public documents. - This part does not provide tutorial material. It is recommended to read parts IEC 61850-5 and IEC 61850-7-1 first, in conjunction with IEC 61850-7-3, and IEC 61850-7-2. This standard is applicable to describe device models and functions of substation and feeder equipment. The concepts defined in this standard are also applied to describe device models 661 and functions for: " substation-to-substation information exchange, " substation-to-control centre information exchange, " power plant-to-control centre information exchange, " information exchange for distributed generation, " information exchange for distribution automation, or " information exchange for metering " information exchanged for hydro power plants " information exchange for wind generation plants Figure 1 provides a general overview of this standard. The groups of logical nodes defined in this standard are shown in Figure 1. For convenience, the logical nodes are defined below in alphabetical order.
