>UNE standards>UNE EN IEC 60034-2-3:2024 - Rotating electrical machines - Part 2-3: Specific test methods for determining losses and efficiency of converter-fed AC motors (Endorsed by Asociación Española de Normalización in June of 2024.)
in stockReleased: 2024-06-01
UNE EN IEC 60034-2-3:2024 - Rotating electrical machines - Part 2-3: Specific test methods for determining losses and efficiency of converter-fed AC motors (Endorsed by Asociación Española de Normalización in June of 2024.)

UNE EN IEC 60034-2-3:2024

Rotating electrical machines - Part 2-3: Specific test methods for determining losses and efficiency of converter-fed AC motors (Endorsed by Asociación Española de Normalización in June of 2024.)

Máquinas eléctricas rotativas. Parte 2-3: Métodos de ensayo específicos para la determinación de las pérdidas y del rendimiento de los motores de c.a. alimentados por convertidor. (Ratificada por la Asociación Española de Normalización en junio de 2024.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
83.60 EUR
English Hardcopy
In stock
83.60 EUR
Standard number:UNE EN IEC 60034-2-3:2024
Pages:43
Released:2024-06-01
Status:Standard
DESCRIPTION

UNE EN IEC 60034-2-3:2024

This part of IEC 60034 specifies test methods and an interpolation procedure for determining losses and efficiencies of converter-fed motors. The motor is then part of a variable frequency power drive system (PDS) as defined in IEC 61800-9-2. Applying the approach of the comparable converter, the motor efficiency determined by use of this document is applicable for comparison of different low voltage motor designs only. The comparable converter approach is not applicable to medium voltage motors. The document also specifies procedures to determine motor losses at any load point (torque, speed) within the constant flux range (constant torque range, base speed range), the field weakening range and the overload range based on determination of losses at seven standardized load points. This procedure is applicable to any variable speed AC motor (induction and synchronous) rated according to IEC 60034-1 for operation on a variable frequency and variable voltage power supply.
