>UNE standards>UNE EN IEC 60309-5:2020 - Plugs, socket-outlets and couplers for industrial purposes - Part 5: Dimensional compatibility and interchangeability requirements for plugs, socket-outlets, ship connectors and ship inlets for low-voltage shore connection systems (LVSC)
in stockReleased: 2020-05-20
UNE EN IEC 60309-5:2020 - Plugs, socket-outlets and couplers for industrial purposes - Part 5: Dimensional compatibility and interchangeability requirements for plugs, socket-outlets, ship connectors and ship inlets for low-voltage shore connection systems (LVSC)

UNE EN IEC 60309-5:2020

Plugs, socket-outlets and couplers for industrial purposes - Part 5: Dimensional compatibility and interchangeability requirements for plugs, socket-outlets, ship connectors and ship inlets for low-voltage shore connection systems (LVSC)

Clavijas, bases de toma de corriente y conectores para usos industriales. Parte 5: Requisitos de intercambiabilidad y compatibilidad dimensional para clavijas, bases de toma de corriente, tomas móviles de barco y bases de conector de barco para sistemas de conexión de baja tensión en tierra (LVSC).

Format
Availability
Price and currency
English PDF
Immediate download
Printable
75.90 EUR
English Hardcopy
In stock
75.90 EUR
Spanish PDF
Immediate download
Printable
75.90 EUR
Spanish Hardcopy
In stock
75.90 EUR
Standard number:UNE EN IEC 60309-5:2020
Pages:24
Released:2020-05-20
Status:Standard
DESCRIPTION

UNE EN IEC 60309-5:2020

This part of 60309 applies to plugs, socket-outlets, ship connectors and ship inlets, hereinafter referred to as accessories, intended to connect ships to dedicated shore supply systems described in IEC 80005-3. This part of IEC 60309 applies to accessories with three phases and Earth with four pilot contacts. NOTE 1 In the USA, the term "Ground" is used instead of "Earth". These accessories have a rated current of 350 A and rated operating voltage not exceeding 690 V 50/60 Hz. These accessories are intended to be installed and operated by instructed persons (IEC 60050- 195:1998, Amendment 1:2001, 195-04-02) or skilled persons (IEC 60050-195:1998, Amendment 1:2001, 195-04-01) only. This standard applies to accessories for primary use outdoors in a seawater environment when the ambient temperature is normally within the range of 25 °C to +40 °C. NOTE 2 In some countries, other ambient temperatures may prevail and may need to be taken into account. These accessories are intended to be connected to cables of copper or copper alloy only. Socket-outlets or ship inlets incorporated in or fixed to electrical equipment are within the scope of this standard. In locations where special conditions prevail, for example where explosions are liable to occur, additional requirements may be necessary.
