>UNE standards>UNE EN IEC 62196-6:2023 - Plugs, socket-outlets, vehicle connectors and vehicle inlets - Conductive charging of electric vehicles - Part 6: Dimensional compatibility requirements for DC pin and contact-tube vehicle couplers intended to be used for DC EV supply equipment where protection relies on electrical separation
in stockReleased: 2023-03-15
UNE EN IEC 62196-6:2023 - Plugs, socket-outlets, vehicle connectors and vehicle inlets - Conductive charging of electric vehicles - Part 6: Dimensional compatibility requirements for DC pin and contact-tube vehicle couplers intended to be used for DC EV supply equipment where protection relies on electrical separation

UNE EN IEC 62196-6:2023

Plugs, socket-outlets, vehicle connectors and vehicle inlets - Conductive charging of electric vehicles - Part 6: Dimensional compatibility requirements for DC pin and contact-tube vehicle couplers intended to be used for DC EV supply equipment where protection relies on electrical separation

Clavijas, bases de toma de corriente, conectores de vehículo y entradas de vehículo. Carga conductiva de vehículos eléctricos. Parte 6: Requisitos de compatibilidad dimensional para acopladores de vehículo de espigas y alveolos en corriente continua para equipos de suministro de corriente continua para vehículos eléctricos donde la protección se basa en la separación eléctrica.

Format
Availability
Price and currency
English PDF
Immediate download
Printable
86.90 EUR
English Hardcopy
In stock
86.90 EUR
Spanish PDF
Immediate download
Printable
86.90 EUR
Spanish Hardcopy
In stock
86.90 EUR
Standard number:UNE EN IEC 62196-6:2023
Pages:35
Released:2023-03-15
Status:Standard
Pages (Spanish):33
DESCRIPTION

UNE EN IEC 62196-6:2023

This document is applicable to vehicle couplers with pins and contact-tubes of standardized configuration, herein also referred to as accessories , intended for use in electric vehicle (EV) conductive charging systems which incorporate control means, with rated operating voltaje up to 120 V DC and rated current up to 100 A. These accessories are intended to be used for a DC interface of the conductive charging system, where the protection against electric shocks relies on electrical separation between the primary circuit and the secondary circuit of the EV supply equipment, specified in IEC 61851-25:201X2. This document applies to accessories and cable assemblies to be used in an ambient temperature of between 30 °C and +50 °C. These accessories and cable assemblies are intended to be connected only to cables with copper or copper-alloy conductors.
