>UNE standards>UNE EN ISO 18183-1:2024 - Geometrical product specifications (GPS) - Partition - Part 1: Vocabulary and basic concepts (ISO 18183-1:2024) (Endorsed by Asociación Española de Normalización in May of 2024.)
in stockReleased: 2024-05-01
UNE EN ISO 18183-1:2024 - Geometrical product specifications (GPS) - Partition - Part 1: Vocabulary and basic concepts (ISO 18183-1:2024) (Endorsed by Asociación Española de Normalización in May of 2024.)

UNE EN ISO 18183-1:2024

Geometrical product specifications (GPS) - Partition - Part 1: Vocabulary and basic concepts (ISO 18183-1:2024) (Endorsed by Asociación Española de Normalización in May of 2024.)

Especificaciones geométricas de productos (GPS). Partición. Parte 1: Vocabulario y conceptos básicos (ISO 18183-1:2024) (Ratificada por la Asociación Española de Normalización en mayo de 2024.)

Format
Availability
Price and currency
English PDF
Immediate download
Printable
71.50 EUR
English Hardcopy
In stock
71.50 EUR
Standard number:UNE EN ISO 18183-1:2024
Pages:27
Released:2024-05-01
Status:Standard
DESCRIPTION

UNE EN ISO 18183-1:2024

This document sets out the basic terminology for partition features and the framework for the fundamental procedures used in partition. The approach is based on the concept of a single surface (single line), where a nominal model is first partitioned into a set of singular surfaces which become an initial set of partition features. This initial set of partition features can then be modified, if required, by GPS modifiers from the specification, to obtain the require set of partitioned features of design intent. This approach allows interpretation of the specification to determine the required set of partition features of design intent in specification and also allows algorithms to be developed that compute the linked measured partition features in verification.
