Homepage>BS Standards>75 PETROLEUM AND RELATED TECHNOLOGIES>75.180 Equipment for petroleum and natural gas industries>75.180.10 Exploratory and extraction equipment>21/30434693 DC BS EN ISO 3421. Petroleum and natural gas industries. Drilling and production equipment. Offshore conductor design, setting depth, and installation
Sponsored link
immediate downloadReleased: 2021-04-26
21/30434693 DC BS EN ISO 3421. Petroleum and natural gas industries. Drilling and production equipment. Offshore conductor design, setting depth, and installation

21/30434693 DC

BS EN ISO 3421. Petroleum and natural gas industries. Drilling and production equipment. Offshore conductor design, setting depth, and installation

Format
Availability
Price and currency
English Secure PDF
Immediate download
26.00 USD
English Hardcopy
In stock
26.00 USD
Standard number:21/30434693 DC
Pages:45
Released:2021-04-26
Status:Draft for Comment
DESCRIPTION

21/30434693 DC


This standard 21/30434693 DC BS EN ISO 3421. Petroleum and natural gas industries. Drilling and production equipment. Offshore conductor design, setting depth, and installation is classified in these ICS categories:
  • 75.180.10 Exploratory, drilling and extraction equipment

This document gives requirements for the design, setting depth and installation of conductors used by the offshore petroleum and natural gas industries. This document covers:

  1. design of the conductor, i.e. determination of the diameter, wall thickness, and steel grade;

  2. determination of the setting depth for three installation methods, namely, driving, drilling/cementing, and jetting;

  3. installation requirements for the installation methods, i.e. selection principles, operating procedures and parameters.

This document is applicable to:

  1. Platform conductors: installed through a guide hole in the platform drill floor and then through guides attached to the jacket at appropriate intervals through the water column to support the conductor withstand metocean actions and prevent excessive displacements.

  2. Jack-up supported conductors: a temporary conductor used only during drilling operations, which is installed by a jack-up drilling rig. In some cases, the conductor is tensioned by tensioners attached to the drilling rig.

  3. Free-standing conductors: a self-supporting caisson in cantilever mode installed in shallow water, typically depths of about 10 m to 20 m. It provides sole support for the well and sometimes supports a small access deck and boat landing.

  4. Subsea wellhead conductors: a fully submerged conductor extending only a few metres above the seafloor.

This document does not apply to drilling risers.
