Homepage>BS Standards>23 FLUID SYSTEMS AND COMPONENTS FOR GENERAL USE>23.040 Pipeline components and pipelines>23.040.60 Flanges, couplings and joints>21/30441534 DC BS EN 1092-3. Flanges and their joints. Circular flanges for pipes, valves, fittings and accessories, PN designated Part 3. Copper alloy flanges
Sponsored link
immediate downloadReleased: 2021-12-23
21/30441534 DC BS EN 1092-3. Flanges and their joints. Circular flanges for pipes, valves, fittings and accessories, PN designated Part 3. Copper alloy flanges

21/30441534 DC

BS EN 1092-3. Flanges and their joints. Circular flanges for pipes, valves, fittings and accessories, PN designated Part 3. Copper alloy flanges

Format
Availability
Price and currency
English Secure PDF
Immediate download
24.21 USD
English Hardcopy
In stock
24.21 USD
Standard number:21/30441534 DC
Pages:56
Released:2021-12-23
Status:Draft for Comment
DESCRIPTION

21/30441534 DC


This standard 21/30441534 DC BS EN 1092-3. Flanges and their joints. Circular flanges for pipes, valves, fittings and accessories, PN designated is classified in these ICS categories:
  • 23.040.60 Flanges, couplings and joints
This document specifies requirements for circular copper alloy flanges and copper alloy collars combined with loose steel plate flanges in PN designations from PN 6 to PN 40 and nominal sizes from DN 10 to DN 1800 in the types shown in Table 1. This document also specifies dimensions and tolerances, materials and their associated pressure/temperature (p/T) ratings, flange facings and related surface finish, weld repairs, and marking, together with information on bolting, gaskets, application/installation and approximate flange masses. The flanges specified, with the exception of integral (type 21) flanges, are for attachment to copper or copper alloy tubes in accordance with EN 12449. NOTE 1 When the flanges specified in this document are required for use with copper or copper alloy tubes to EN 1057 in those tube diameters which are different to EN 12449, this should be agreed between the equipment manufacturer and the flange manufacturer. NOTE 2 The size of copper and copper alloy tubes is designated by reference to the outside diameter in millimetres. NOTE 3 See also Annex B. NOTE 4 Non-gasketed pipe joints are outside the scope of this document. Table 1 - Types of flanges and collars [...table not represented...]
