Homepage>BS Standards>49 AIRCRAFT AND SPACE VEHICLE ENGINEERING>49.060 Aerospace electric equipment and systems>23/30477004 DC BS EN 3155-074. Aerospace series. Electrical contacts used in elements of connection Part 074. Contacts, electrical, quadrax, size 8, male, type E, crimp, class R. Product standard
immediate downloadReleased: 2023-07-14
23/30477004 DC BS EN 3155-074. Aerospace series. Electrical contacts used in elements of connection Part 074. Contacts, electrical, quadrax, size 8, male, type E, crimp, class R. Product standard

23/30477004 DC

BS EN 3155-074. Aerospace series. Electrical contacts used in elements of connection Part 074. Contacts, electrical, quadrax, size 8, male, type E, crimp, class R. Product standard

Format
Availability
Price and currency
English Secure PDF
Immediate download
22.22 USD
English Hardcopy
In stock
22.22 USD
Standard number:23/30477004 DC
Pages:18
Released:2023-07-14
Status:Draft for Comment
DESCRIPTION

23/30477004 DC


This standard 23/30477004 DC BS EN 3155-074. Aerospace series. Electrical contacts used in elements of connection is classified in these ICS categories:
  • 49.060 Aerospace electric equipment and systems
This document specifies the required characteristics, tests and tooling applicable to male electrical quadrax contacts, shielded, size 8, type E type E characteristic impedance 100 Ω, crimp, class R, used in elements of connection according to EN 3155-002. It shall be used together with EN 3155-001. The associated female contacts are defined in EN 3155-075.
