BS 1104:1957 Specification for general purpose Acme screw threads

BS 1104:1957

Specification for general purpose Acme screw threads

Format
Availability
Price and currency
English Secure PDF
Immediate download
317.20 USD
English Hardcopy
In stock
317.20 USD
Standard number:BS 1104:1957
Pages:42
Released:1957-06-05
ISBN:0 580 35250 1
Status:Standard
DESCRIPTION

BS 1104:1957


This standard BS 1104:1957 Specification for general purpose Acme screw threads is classified in these ICS categories:
  • 21.040.01 Screw threads in general

This British Standard recommends a Standard Series of diameters and associated pitches for General Purpose Acme form screw threads, for the nominal size range ¼ in. to 5 in. and specifies the limiting dimensions, tolerances and allowances for four classes of thread.

Information is also provided whereby the limiting dimensions for any other screw thread of Acme form may be determined, but the use of these special diameter/pitch combinations should be avoided wherever possible.

Recommendations are given in Section 2 regarding the types and dimensions of gauges to be used.


Defines Acme thread; tables of basic sizes, limits and tolerances for standard series of single start threads ¼ in to 5 in diameter. Agrees with ASA B1.5:1952 except for pitches associated with diameters ⅜ in, $9G in, 1 in, 1¼ in and 1½ in. 2G, 3G and 4G fits in the American standard included, together with finer class, 5G. Tables of effective diameter tolerances for extended range of diameter/pitch combinations are provided. From these and related tables limiting dimensions for any special diameter/pitch combination for single or multi-start Acme thread can be calculated.
