BS 2856:1973 Precise conversion of inch and metric sizes on engineering drawings

BS 2856:1973

Precise conversion of inch and metric sizes on engineering drawings

Format
Availability
Price and currency
English Secure PDF
Immediate download
167.05 USD
English Hardcopy
In stock
167.05 USD
Standard number:BS 2856:1973
Pages:16
Released:1973-10-08
ISBN:0 580 07752 7
Status:Standard
DESCRIPTION

BS 2856:1973


This standard BS 2856:1973 Precise conversion of inch and metric sizes on engineering drawings is classified in these ICS categories:
  • 01.100.01 Technical drawings in general
  • 01.060 Quantities and units
  • 17.040.10 Limits and fits

This British Standard provides a procedure for conversion which will give the essential accuracy required for precise dimensional interchangeability.

The standard lays down an optimum fineness of rounding the converted size so that the conversion is made with the required precision and, at the same time, an excessive number of decimal places in the converted size is avoided. The procedure adopted is designed to ensure correct acceptance or rejection of a component, with respect to sizes, whether manufactured in one system of units or the other, provided that the methods of measurement used in the two systems are of comparable accuracy.

The conversion factor used is: 1 inch = 25.4 millimetres.

This conversion factor is exact. It results from the legal definition of the yard in terms of the metre adopted by the USA in 1959 and by the UK in the Weights and Measures Act 1963. The values given in the tables in Appendix A are taken to a sufficient number of decimal places to cover the finest rounding required by the rules for conversion of inch and millimetre sizes.


Provides a procedure for the conversion of inch and metric sizes on engineering drawings which will give the essential accuracy required for precise dimensional interchangeability. The standard gives specific guidance on the optimum fineness of rounding the converted size, and recommends a procedure for conversion which takes the form of simple rules covering successive steps in the conversion. Examples of the application of the rules are given for a variety of cases. Tables of conversion from inches to millimetres, and vice versa, are included in an appendix to facilitate the work.
