BS 3063:1965 Specification for dimensions of gaskets for pipe flanges

BS 3063:1965

Specification for dimensions of gaskets for pipe flanges

Format
Availability
Price and currency
English Secure PDF
Immediate download
319.91 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
31.99 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
95.97 USD
English Hardcopy
In stock
319.91 USD
Standard number:BS 3063:1965
Pages:34
Released:1965-07-26
ISBN:0 580 35583 7
Status:Standard
DESCRIPTION

BS 3063:1965


This standard BS 3063:1965 Specification for dimensions of gaskets for pipe flanges is classified in these ICS categories:
  • 23.040.80 Seals for pipe and hose assemblies

This British Standard specifies the “plan” dimensions of gaskets suitable for use with flanges to BS 107), BS 17708) and BS 20359).

This standard does not include spiral edge-wound or other special types of gasket.

Dimensions of gaskets for use with flanges to BS 10, Table K, Table R and Table S have been limited to sizes up to and including 15 in, 5 in and 3 in flange size designations respectively and no gasket dimensions have been standardized for BS 10, Table T. This is because wide variations may occur in the actual inside diameters of steel pipes fitted with flanges of the same size designations to the higher tables of BS 10. In such cases, it is not practicable to specify the inside diameter of gaskets and there would be little advantage in specifying the outside diameters only.

NOTE Gasket dimensions for flanges for the petroleum industry are given in the British Standards for pipe flanges and gaskets for the petroleum industry, BS156010), BS 329311), BS 338112), BS 157513) and BS 157614).


'Plan' dimensions for 'inside bolt circle' and 'full face' gaskets or pipe flanges in accordance with BS 10 and BS 2035, and 'full face' gaskets for flanges to BS 1770. The tables giving dimensions bear the same designation as the flange tables in the appropriate pipe flange standard. Marking of gaskets for purchasing and identification.
