BS 3818:1964

This standard BS 3818:1964 Specification for self-sealing fuelling couplings for diesel locomotives and diesel railcars is classified in these ICS categories:

• 45.040 Materials and components for railway engineering

This British Standard specifies the leading dimensions for 1/ in and 2/ in nominal bore screw-engagement self-sealing fuelling couplings for diesel locomotives and diesel railcars, for use at a pressure not exceeding 100 lbf/in², detailed as follows:

1. Hose half coupling.
2. Fixed half coupling for mounting on vehicle.
3. Blanking cap for fixed half coupling to keep the sealing faces clean and arrest leakage (optional).
4. Dust cap for hose half coupling (optional).

Screw-engagements coupling, 1½ in and 2½ in nominal bore. Leading dimensions, functional and test requirements. Couplings, fixed half couplings, blanking (dust) caps, and method of functioning illustrated.
