immediate downloadReleased: 1984-05-31
BS 673:1984 Specification for shanks for pneumatic tools and fitting dimensions of chuck bushings

BS 673:1984

Specification for shanks for pneumatic tools and fitting dimensions of chuck bushings

Format
Availability
Price and currency
English Secure PDF
Immediate download
270.40 USD
English Hardcopy
In stock
270.40 USD
Standard number:BS 673:1984
Pages:28
Released:1984-05-31
ISBN:0 580 13836 4
Status:Standard
DESCRIPTION

BS 673:1984


This standard BS 673:1984 Specification for shanks for pneumatic tools and fitting dimensions of chuck bushings is classified in these ICS categories:
  • 25.140.10 Pneumatic tools

This International Standard relates to shanks for pneumatic tools and corresponding chuck bushings and deals with the following types:

  • coal pick shanks;
  • chisel shanks;
  • rivet snap shanks, parallel;
  • rivet snap shanks, tapered;
  • breaker and spade shanks;
  • concrete breaker shanks;
  • rock drill shanks.

The types relate to the machine for which they are mainly designed, but this does not prevent the use of the shanks for other applications.

Other types of tools will be dealt with in further International Standards when the corresponding studies are completed.

Pneumatic hammers and their chuck bushings are not covered by this International Standard but those features of chuck bushings (dimensions and tolerances) which ensure interchangeability are specified. For each tool mentioned above, this International Standard provides tables giving dimensions in millimetres.

Dimensions in inches are given in the Annex which be valid for five years from the date when this International Standard is approved.


Covers the following types: coal pick shanks, chisel shanks, rivet snap shanks - parallel and tapered, breaker and spade shanks, concrete breaker shanks and rock drill shanks. Designations for each type.
