BS 7076-3:1989 Dimensions of gaskets for flanges to BS 1560 Specification for non-metallic envelope gaskets

BS 7076-3:1989

Dimensions of gaskets for flanges to BS 1560 Specification for non-metallic envelope gaskets

Format
Availability
Price and currency
English Secure PDF
Immediate download
165.20 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
16.52 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
49.56 USD
English Hardcopy
In stock
165.20 USD
Standard number:BS 7076-3:1989
Pages:8
Released:1990-01-31
ISBN:0 580 17273 2
Status:Standard
DESCRIPTION

BS 7076-3:1989


This standard BS 7076-3:1989 Dimensions of gaskets for flanges to BS 1560 is classified in these ICS categories:
  • 23.040.80 Seals for pipe and hose assemblies

This Part of BS 7076 specifies the dimensions and marking of IBC (inside bolt circle) non-metallic envelope gaskets for use with flanges complying with BS 1560 : Sections 3.1, 3.2 and 3.3 for Class designations 150 and 300 for sizes up to and including 24.

NOTE 1. The titles of the publications referred to in this standard are listed on the inside back cover.

NOTE 2. Dimensions of other types of gaskets for use with flanges complying with BS 1560 : Sections 3.1,3.2 and 3.3 are given in BS 3381 and BS 7076 : Parts 1,2 and 4 (see foreword).

NOTE 3. Dimensions of non-metallic envelope gaskets for use with flanges complying with BS 4504 : Sections 3.1,3.2 and 3.3 are given in BS 4865 : Part 3.

NOTE 4. Appendix A lists information that should be supplied by the purchaser when ordering gaskets.


Dimensions and marking of IBC gaskets for flanges to BS 1560 having Class designations 150 and 300 and for sizes up to and including 24.
