BS EN 1364-5:2026

This standard BS EN 1364-5:2026 Fire resistance tests for non-loadbearing elements is classified in these ICS categories:

• 13.220.50 Fire-resistance of building materials and elements
• 91.060.99 Other elements of buildings

This document specifies a method for determining the fire resistance of air transfer grilles (ATG). It is applicable to air transfer grilles intended for installation in building components (typically walls, floors or ceilings). The orientation of the installation of the air transfer grille can be vertical or horizontal. The closing mechanism of the air transfer grille can come from expansion of material and/or from any mechanical or electrical closing device. This document is applicable to fire resistant or fire resistant and smoke control air transfer grilles. An additional test configuration is valid for fire resistant or fire resistant and smoke control air transfer grilles in applications where flame impingement is a risk during open state from start of fire (see Annex A). This document evaluates the behaviour of the air transfer grille when exposed to the heating curve described in EN 1363 1 and the standard pressure described in EN 1363 1. It is not the intention of this test to provide quantitative information on the rate of leakage of smoke and/or hot gases or on the transmission or generation of fumes under fire conditions. Such phenomena are only noted in describing the general behaviour of test specimens during the test. The determination of the rate of leakage of smoke at ambient temperature or at 200 °C as an optional requirement for ATG with declared smoke control is specified in EN 1634 3. This document is not applicable to the determination of the fire resistance of air transfer grilles that are used in ducts because ATG are considered as separating elements. The test method for ATG used in ducts is described in the corresponding duct standards. This document is not applicable to the determination of the fire resistance of a fire damper or a fire barrier connected to a duct one or both sides, as an ATG is tested as a fire-separating element on its own. Fire dampers are tested according to EN 1366 2. Non-mechanical fire barriers are tested according to EN 1366 12. This document is not applicable to the determination of the fire resistance of air transfer grilles in fire doors, shutters and openable windows as specified in EN 1634 1 and EN 1364 2, because the deformation of fire doors, shutters and openable windows in fire conditions differs from the deformation of flexible/rigid walls. Moreover, the location of thermocouples in the door standard is too specific to be handled in this document. All values given in this document are nominal unless otherwise specified.

BS EN 1364-5:2026 Fire Resistance Tests for Non-Loadbearing Elements Air Transfer Grilles

Introducing the BS EN 1364-5:2026, a comprehensive standard that sets the benchmark for fire resistance testing of non-loadbearing elements, specifically focusing on air transfer grilles. This standard is an essential resource for professionals in the construction and safety industries, providing detailed guidelines and methodologies to ensure the highest levels of fire safety and compliance.

Key Features

• Standard Number: BS EN 1364-5:2026
• Pages: 32
• Release Date: July 28, 2026
• ISBN: 978 0 539 30804 4
• Status: Standard

Overview

The BS EN 1364-5:2026 standard is meticulously crafted to address the critical aspects of fire resistance in air transfer grilles, which are integral components in modern building designs. These grilles play a vital role in ventilation systems, and their ability to withstand fire is crucial for maintaining safety and integrity in the event of a fire.

Why Choose BS EN 1364-5:2026?

This standard is indispensable for architects, engineers, safety inspectors, and manufacturers who are committed to upholding the highest safety standards. By adhering to the guidelines set forth in BS EN 1364-5:2026, professionals can ensure that air transfer grilles meet rigorous fire resistance criteria, thereby enhancing the overall safety of buildings.

Comprehensive Testing Procedures

The standard provides a detailed framework for conducting fire resistance tests, ensuring that all aspects of the grille's performance are evaluated. This includes assessing the grille's ability to prevent the spread of fire and smoke, which is crucial for protecting occupants and minimizing damage.

Enhanced Safety and Compliance

Compliance with BS EN 1364-5:2026 ensures that air transfer grilles are capable of maintaining their integrity under fire conditions, thereby contributing to the overall fire safety strategy of a building. This standard is aligned with international safety regulations, making it a reliable choice for projects worldwide.

Who Should Use This Standard?

The BS EN 1364-5:2026 is designed for a wide range of professionals, including:

• Architects and Designers
• Construction Engineers
• Fire Safety Inspectors
• Manufacturers of Air Transfer Grilles
• Building Code Officials

Benefits of BS EN 1364-5:2026

By implementing the guidelines of this standard, professionals can achieve several benefits:

• Improved Safety: Ensure that air transfer grilles provide effective barriers against fire and smoke.
• Regulatory Compliance: Meet and exceed local and international fire safety regulations.
• Quality Assurance: Guarantee that products meet the highest standards of performance and reliability.
• Market Advantage: Gain a competitive edge by offering products that are certified to the latest safety standards.

Conclusion

The BS EN 1364-5:2026 standard is a vital tool for ensuring the fire resistance of air transfer grilles, providing a robust framework for testing and compliance. By integrating this standard into your projects, you can enhance safety, meet regulatory requirements, and deliver superior quality products. Stay ahead in the industry by adopting the latest standards in fire safety.
