BS EN 13709:2010 Industrial valves. Steel globe and globe stop and check valves

BS EN 13709:2010

Industrial valves. Steel globe and globe stop and check valves

Format
Availability
Price and currency
English Secure PDF
Immediate download
181.45 USD
English Hardcopy
In stock
181.45 USD
Standard number:BS EN 13709:2010
Pages:20
Released:2010-06-30
ISBN:978 0 580 68322 0
Status:Standard
DESCRIPTION

BS EN 13709:2010


This standard BS EN 13709:2010 Industrial valves. Steel globe and globe stop and check valves is classified in these ICS categories:
  • 23.060.10 Globe valves

This European Standard specifies the requirements for steel globe and globe stop and check valves which are wrought, cast or fabricated in straight, angle or oblique pattern with end connections flanged, butt welding, socket welding or threaded.

This standard is applicable to steel globe and globe stop and check valves mainly used for industrial and general purpose applications. However, they can be used for other applications provided the requirements of the relevant performance standards are met.

The range of nominal sizes covered is:

DN 8; DN 10; DN 12; DN 15; DN 20; DN 25; DN 32; DN 40; DN 50; DN 65; DN 80; DN 100; DN 125; DN 150;

DN 200; DN 250; DN 300; DN 350; DN 400.

DN 8 and DN 12 are not used for PN designated flanged end connections.

DN 8, DN 10 and DN 12 are not used for Class designated flanged end connections. Socket welding end valves and threaded end valves are limited to the range DN 8 to DN 65. The range of pressure designations covered is:

  1. for flanged and butt welding end valves:

    1. PN 10; PN 16; PN 25; PN 40; PN 63; PN 100;

    2. Class 150; Class 300; Class 600.

  2. for socket welding end valves and threaded end valves:

    1. 3) PN 40; PN 63; PN 100;

    2. 4) Class 600; Class 800.

NOTE Class 800 is a Class designation widely used for socket welding and threaded end valves.
