BS EN 50089:2022 - TC Tracked Changes. High-Voltage switchgear and controlgear. Insulating pressurised partitions for gas filled metal enclosures

BS EN 50089:2022 - TC

Tracked Changes. High-Voltage switchgear and controlgear. Insulating pressurised partitions for gas filled metal enclosures

Format
Availability
Price and currency
English Secure PDF
Immediate download
254.80 USD
English Hardcopy
In stock
254.80 USD
Standard number:BS EN 50089:2022 - TC
Pages:52
Released:2023-03-17
ISBN:978 0 539 25198 2
Status:Tracked Changes
DESCRIPTION

BS EN 50089:2022 - TC


This standard BS EN 50089:2022 - TC Tracked Changes. High-Voltage switchgear and controlgear. Insulating pressurised partitions for gas filled metal enclosures is classified in these ICS categories:
  • 29.130.10 High voltage switchgear and controlgear
This document applies to pressurized partitions used in indoor and outdoor installations of high-voltage AC and DC switchgear and controlgear with rated voltages (Ur) above 1 kV AC / 1,5 kV DC and with design pressure higher than 300 kPa, where the gas is used principally for its dielectric and/or arc-quenching properties. The partitions comprise pressurized barriers in electrical equipment not necessarily limited to the following examples: - circuit-breakers; - switch-disconnectors; - disconnectors; - earthing switches; - current transformers; - voltage transformers; - surge arresters; - busbars and connections; - cable connections/terminations; - cable bushings. Partitions which are only pressurized from one side are also covered. 1 kV AC / 1,5 kV DC means it is valid for the apparatus applied and where the partitions are installed; however, the application of voltages below 1 kV AC / 1,5 kV DC as in, for example, current and voltage transformers are not excluded. This document does not apply to high voltage bushings (see EN 60137, EN 61462 and EN 62155).
