BS EN 50673:2019 Plug-in type bushings for 72,5 kV with 630 A and 1 250 A for electrical equipment

BS EN 50673:2019

Plug-in type bushings for 72,5 kV with 630 A and 1 250 A for electrical equipment

Format
Availability
Price and currency
English Secure PDF
Immediate download
195.00 USD
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
19.50 USD
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
58.50 USD
English Hardcopy
In stock
195.00 USD
Standard number:BS EN 50673:2019
Pages:18
Released:2019-03-22
ISBN:978 0 539 00235 5
Status:Standard
DESCRIPTION

BS EN 50673:2019


This standard BS EN 50673:2019 Plug-in type bushings for 72,5 kV with 630 A and 1 250 A for electrical equipment is classified in these ICS categories:
  • 29.080.20 Bushings

This document is applicable to plug-in type bushings, according to EN 60137, 72,5 kV, rated currents from 630 A up to 1 250 A and frequencies from 15 Hz up to 60 Hz for single or three-phase arrangements in electrical equipment like liquid filled transformers or gas insulated switchgear and controlgear. It complements and amends, if necessary, the relevant EN standards.

The application of such plug-in type bushings is derived from EN 50180 and EN 50181 but applied for higher voltages with described deviations to EN 50299-2 and EN 62271-209.

This standard does not cover the connection assembly as described in EN 50299-2 and EN 62271-209.

EN 60137 and HD 632 series outline the qualification, type test, routine and sample test of plug-in type bushings according to this standard.

This document establishes essential dimensions and testing procedures, to ensure adequate mounting and interchangeability of mating plug-in separable connectors of equivalent ratings.
